Frame
Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
-
Fork (Size S)
SR Suntour XCR 34, air spring, 2CR damper, hydraulic lockout, tapered steerer, 44 mm offset, Boost 110, 15 mm bolt-on thru axle, 100 mm travel
-
Fork (Sizes M, L, XL)
SR Suntour XCR 34, air spring, 2CR damper, hydraulic lockout, tapered steerer, 44 mm offset, Boost 110, 15 mm bolt-on thru axle, 120 mm travel
-
Hub front
Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
-
Hub rear
Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
-
Skewer rear
Bontrager Switch thru axle, removable lever
-
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
-
Tyre (Size S)
Bontrager Montrose Comp, wire bead, 30 tpi, 27.5x2.40"
-
Tyre (Sizes M, L, XL)
Bontrager Montrose Comp, wire bead, 30 tpi, 29x2.40''
-
Max tyre size
Frame: 29x2.50" (S: 27.5x2.50"), Fork: see manufacturer
-
Battery
Bosch PowerTube 800 Wh, smart system
-
Charger
Bosch standard 2A, 230V, smart system
-
Computer
Bosch Purion 200
-
Motor
Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)
-
Shifter
Shimano U6000, 10-speed
-
Rear derailleur
Shimano CUES U6000 GS
-
Crank
FSA Bosch CK-220, 36T ring, 165 mm length
-
Chainring
FSA, 36T, steel
-
Cassette
Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
-
Chain
Shimano LG500, 9/10/11-speed
-
Pedal
VP-536 nylon platform
-
Max. chainring size
1x: 38T
-
Saddle
Bontrager Commuter Comp
-
Seatpost (Size S)
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
-
Seatpost (Size M)
Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length
-
Seatpost (Sizes L, XL)
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
-
Handlebar
Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
-
Grips
Bontrager XR Endurance Comp, lock-on, Trek Ergonomic Comp, lock-on
-
Stem
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
-
Head set
FSA IS-2, 1-1/8" top, 1.5" bottom
-
Brake rotor
Tektro, CentreLock, 203 mm
-
Brake Set
Tektro HD-M275 hydraulic disc
-
Rotor size
Max brake rotor sizes – Frame: 220 mm, min 180 mm, Fork: see fork manufacturer
-
Tool
Bontrager Switch thru axle, removable lever
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lbs).
